Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor

    Buy cheap Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor from wholesalers

    Buy cheap Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor from wholesalers
    • Buy cheap Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor from wholesalers
    • Buy cheap Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor from wholesalers

    Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor

    Ask Lasest Price
    Brand Name : Yuxunion
    Model Number : ET800D
    Certification : CE/FCC/ROHS
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000sets/day
    Delivery Time : 10-20days
    • Product Details
    • Company Profile

    Web Monitoring Fuel GPS Tracker Anti Theft With Built - In Fuel Sensor

    Free Web Monitoring 2G 3G GPS Tracker with Built-in Fuel Sensor Fits Fleet Management


    Specification:


    GPS Bands

    GMS850/900/1800/1900

    GSM Type

    HUAWEI MG301

    GPS Chip

    Ublox

    GPS Sensitivity

    -159dBm

    GPS Frequency

    L1 / 1575.42MHz

    C/A Code

    1.023 MHz chip rate

    PIN

    20 PINs

    Position Accuracy

    10 Meters

    Velocity Accuracy

    0.1 m/s

    GPS Level

    Industrial Level

    Voltage

    DC 10-36V

    Hot Start Time

    1s

    Warm Start Time

    38s

    Cold Start Time

    42s

    Working Temperature

    -25℃-70℃

    Plastic

    Aluminum Alloy

    Waterproof

    IP67

    Certification

    CE FCC RoHS ISO:9001

    Humidity

    5%-90%

    Atmospheric Pressure

    86-106KPa


    Description:


    Fuel Consumption:

    • Fuel Volume Monitoring

    • Fuel Low-Level Alarm

    • Fuel Abnormal Increase Alarm

    • Fuel Abnormal Decrease Alarm

    Alarm:

    • Emergency Alarm

    • ACC Off Alarm

    • SOS Alarm

    • Device Damage Alarm

    • Geofence Alarm

    • Overspeed Alarm

    Location:

    • Real-timing Report

    • Distance Report

    • Location Report

    • Geofence Report

    • Speed Report

    • Mileage Report

    • Mobile Phone APP Report

    Others:

    Battery Protection

    GPS Antenna Monitoring

    Communication

    Remote Config

    Firmware Upgrade


    Accessories Options:

    1. Door Sensor

    2. Temperature Sensor

    3. RFID

    4. Magnetic Card

    5. Camera

    ET800D 20PIN Definition

    PIN No.

    Definition

    Cable Color

    Remark

    1

    VBAT+

    Thick red

    Car battery BAT+

    2

    VBAT-

    Thick Black

    Car Battery BAT-

    3

    ACC-CK-IM

    Yellow

    Car ACC

    4

    ALM-IM


    Car Alarm Input

    5

    OUT

    Gray

    Output

    6

    Lock-Car

    Red

    Car Lock Output

    7

    OIL-IN

    Green

    Fuel Consumption Input

    8

    IN1

    Blue

    Input 1

    9

    IN2

    Purple

    Input 2

    10

    IN3

    Orange

    Input 3

    11

    232-RXD

    Yellow

    RS232/TTL Receive

    12

    232-TXD

    Green

    RS232/TTL Send

    13

    GND

    Black +Black

    DC 5V Ground

    14

    +5V-OUT

    Red +Red

    5V+

    15

    485-B

    Green

    485/TTL Communication port B

    16

    485-A

    Yellow

    485/TTL Communication port A

    17

    CAN_H-

    Black

    CAN H-

    18

    CAN_H+

    Red

    CAN H+

    19

    MIC2P

    Red

    Microphone P

    20

    MIC2N

    Black

    Microphone N


    Application:


    1. Fleet Management

    2. Logistics

    3. Transport

    4. Travel

    5. Rent Car

    6. IT Company

    7. Taxi

    8. School Bus


    Comparison:


    • Lifetime Warranty

    • Industrial Quality

    • Double PCB Boards, Device is more stable

    • Free Built The Platform for Customer

    How To Order:


    1. Please send the below quote to me.

    2. Or Add my WhatsApp: +8618143091279

    3. Maybe my email: sales05@ywteck.com


    FAQ:


    Q: What's your MOQ?


    A: 100pcs


    Q: Do you support the sample?


    A: Yes


    Q: How to help me to build a free platform?


    A: The first order 300pcs, we support to build a free platform for you, or please contact the sales and get more solutions.


    Q: How to add your device protocol into my platform?


    A: We have the engineering team, please contact us and get more details.


    Q: What payment terms do you support?


    A: PayPal, T/T, Western Union...are available.
